Twist Lock Push Pull Control Cable For Remote Operation
Product Description：
A twist lock push pull control cable is a type of control cable mechanism that combines the functionalities of both a push-pull control cable and a twist lock mechanism. This design allows for the cable to be pushed or pulled to actuate a function, and then locked in place by twisting a component to secure the cable in a specific position.The twist lock feature in this control cable provides an additional level of safety and security by preventing unintended movement or disengagement of the cable once it is set in a desired position.
Specifications
| Certificate: | IATF16949 |
| Handle Type: | Twist Lock |
| Features: | High Temperature Resistance, Low Loss , Long Service Life |
| Handle Material: | Stainless Steel Or Plated Carbon Steel / Plastic Coated Carbon Steel Conduit And Inner Member / Plastic Seal / Plastic Knob |
| Cable Length: | Customizable |
| Stroke: | Customizable |
| Applications: | Vehicles, Boat, Aircraft, Etc |
| Process: | Cutting, Welding, Punching |
| Cable Color: | Green, Black,Grey |
| Conduit Material: | PVC, PE, Etc |
Applications
● Engine shut down
● Engine choke
● Latch operation
● Valve operation
Features
● Built tough for push-pull operations.
● Locking feature keeps cable in position.
● Available in lengths from 6 ft to 30 ft.
Function
Self-locking, micro adjustment by rotating handle, control a push pull cable or a pull cable.
Specification
